Level Sensors

HydroBar G II

Part No. HSB0 HG

Screw-in with capacitive ceramic measurement cell

Screw-in probe with internal 4 - 20 mA transmitter for hydrostatic level measurement in water, wastewater and gases. Oil-free capacitive ceramic measurement cell.

  • Robust and reliable screw-in probe with 1.5“ threaded connection
  • Capacitive ceramic measurement cell
  • for slight to heavily polluted liquids, sludge and pasty media
  • Large front-flush diaphragm
  • 2-wire probe
  • Ex Zone 0
  • High overpressure resistance
  • Integrated overvoltage protection

The hydrostatic level probe with G 1.5” thread has been developed to meet the high demands of industry and environmental protection.

The corrosion-proof encapsulation featuring IP68 protection rating allows to use the unit for reliable level detection in containers, tanks and pipelines. The large resistant ceramic diaphragm has proven particularly in the wastewater sector as well as in the chemical industry. Due to the front-flush diaphragm the unit can be used even in viscous media and pastes. Diaphragm failures are virtually eliminated.The HydroBar G II can be used in aggressive media such as acids and caustic solutions as well.

Utilising the widely used 2-wire technology, the installation costs are very low.The unit is optionally available with a 4-character LCD integrated into the enclosure lid for indication of measurement values.

Typical applications for HydroBar G II

  • Pump stations
  • Pipelines
  • Containers and tanks
  • Digester outlets
  • Industrial applications
  • and many more
Common
Power supply 12 to 36 V DC
Ex: 12 to 28 V DC
Enclosure Stainless steel 1.4305
diaphragm: ceramics (AL2O3)
Process connection G1½” DIN ISO 3852
stainless steel 1.4571
Protection IP 68
Measurement principle capacitive
Measurement ranges / permissible overpressure 1 mH2O / 2 bar
2 mH2O / 2 bar
4 mH2O / 4 bar
6 mH2O / 4 bar
10 mH2O / 7 bar
20 mH2O / 10 bar
1 bar / 7 bar
2 bar / 10 bar
4 bar / 25 bar
6 bar / 25 bar
10 bar / 40 bar
20 bar / 60 bar
special measurement ranges upon request

Accuracy according to IEC 60770 0,25 % / 0,35 % FSO
Long-term stability ± 0,1 % FSO / year
Ex-Approval II 1G Ex ia IIC/IIB T4, IBEx U05 ATEX 1193X
Operating temperature -10 °C to +85 °C
Permissible medium temperature -25 °C to +125 °C
Storage temperature -40 °C to +100 °C
Outputs 4 - 20 mA, 2-wire
Load 600 Ohm / 24 V
1000 Ohm / 32 V

Specifications subject to change.

Declaration of Conformity "Pressure Probe"

Declaration of Conformity "Pressure Probe" Ex
