Level Sensors

NivuCompact Echo Sounder

Part No. NMC

for level and volume measurement

Ultrasonic compact echo sounder in 2- and 3-wire version for non-contact measurement of distance, level, empty space or volume. Parameters can be set directly on site without the need to open the enclosure.

  • Combi unit with sensor and transmitter
  • Measurement range from 0.2 to 10 m
  • Digital echo processing and linearisation
  • Ideal even for battery operation thanks to very short startup and measurement times
  • View echo profiles on PC
  • Unit can be programmed on sit without opening the enclosure
  • Integrated temperature compensation
  • ATEX Approval for Ex-Zone 1

The NivuCompact is a compact echo sounder for non-contact ultrasonic measurement of level, distance, space or volume. NivuCompact can be used wherever reliable non-contact level measurement is required.
Thanks to its very quick startup time of 4 seconds until value output, the NivuCompact is particularly suitable for battery-powered logger operation. High transducer power and tight beam angle in addition with digital echo pro-cessing make the NivuCompact an ideal tool for many "difficult" applications. The integrated display makes programming extremely simple. The NivuCompact is available as 2- or 3-wire version in one unit.



Typical Applications

  • Wastewater: screening plants, flow control sections in stormwater treatment plants, volume measurements in tanks such as precipitants and similar, irrigation plants
  • Drinking water: tank level measurements, water treatment
  • Power generation: cooling water circuits, hydropower plants
  • Industry: liquid level measurement in tanks and containers
Common
Power supply 11 - 30 V (12 - 28 V in Ex version)
Enclosure material: Valox 357 PBT PVDF
Protection IP 65
Measurement range NMC 03: 0.2 m - 3 m
NMC 06: 0.3 m - 6 m
NMC 10: 0.3 m - 10 m
Transmit frequency 125 KHz
Beam angle <10°
Measurement uncertainty ±0.25 % of measurement value
Resolution 2 mm
Outputs 4 - 20 mA, resolution 5 µA
Functions level, distance, empty space and volume
Ex-Approval II 1 G Ex ia IIC T4 (only 2-wire version without interface)
Operating temperature Process: -40 ºC to +80 ºC
Ambient: -20 ºC to +65 ºC
Startup time 4 sec. typical
Installation using BSP or NPT thread
1.5” (3 m/6 m versions)
2” (10 m versions)

Specifications subject to change.
